CBB61 Insert Series

Product description:


Adopt electrician grade polypropylene film as the dielectric, thicken type metalized electrode, 94V0 grade frame retardant plastic shell, epoxy resin encapsulation, standard type quick connect terminal lead, have many characteristics such as high self-healing, electrical performance stable etc.

Parameters:

1.Certification marks: UL﹑VDE﹑CQC

2.Executing standards: GB/T3667 、 UL810 、EN60252

3.Climate type: 25/70/21、25/85/21、40/70/21、40/85/21

4.The rated voltage: 250VAC, 450VAC, 500VAC, (50/60Hz)

5.Capacity range: 1μF~15μF

6.Capacitance tolerance: ±5%(J)、±10%(K)、±105%(U)

7.Testing voltage:   Ut-t   2*UN (VAC)/60s

Ut-c  2*UN+1000(VAC)/ 60s(≥2000VAC)

8.Insulation resistance(20℃):Ut-c  ≥2000MΩ (500VDC,60s)

9.Loss angle tangent(20℃):≤0.002 (100Hz )
