Current Position: Home --> Products --> Motor Capacitor
CBB60


Product description:


Select high quality electrician grade polypropylene film as the dielectric, select composite type high purity metal as the electrode, dry-type structure design, flame retardant plastic shell or metal aluminum shell and the epoxy resin sealing, the security level is P2 or P0 optional.

This series of products with high performance price ratio, high withstand voltage strength, long life and other characteristics, is mainly suitable for water pump, washing machine, paper shredder and other AC motor’s starting and running.


Parameters:

1.Certification mark: UL﹑VDE﹑CQC

2.Executing standards: GB/T3667、 UL810 、EN60252

3.Climate type: 25/70/21、25/85/21、40/70/21、40/85/21

4.The rated voltage: 150VAC~600VAC (50/60Hz)

5.The capacity range: 1μF~80μF

6.Capacitance tolerance: ±5%(J)、±10%(K)、±105%(U)

7.Testing voltage:  Ut-t   2*UN (VAC)/60s

Ut-c  2*UN+1000(VAC)/ 60s(≥2000VAC)

8.The insulation resistance(20℃): Ut-t  ≥2000MΩ .μF (500Vdc,60s)

9.Loss angle tangent(20℃):≤0.002 (100Hz )

10.Protection level: P0 / P2

11.Fault current: 10,000AFC (UL810)
